| Connection Cross Section: |
0.14 … 1.0 mm² |
| Rated insulation voltage Ui: |
250 V |
| Rated impulse voltage Uimp: |
2.5 kV |
| Short circuit protection according to IEC 60269-1: |
6A gG |
| thermal rated current Ith: |
6 A |
| Approach speed: |
0.01 … 50 m/min |
| Number of switching elements: |
3 |
| Design: |
upright |
| Actuating force: |
min. 15 N |
| Installation Orientation: |
any |
| Mechanical Life: |
10 x 10? |
| Switching principle: |
Snap-action switching contact(Contact bounce time ? 2 ms) |
| Degree of protection: |
IP67 |
| Plunger spacing: |
8 mm |
| Ambient temperature: |
-5 … +80 °C |
| Item designation: |
SB03R08-552-M |
| Gross weight: |
0,156kg |
| ECLASS: |
27-27-06-02 Multi-position switch |
| Number of changeover contacts: |
3 |
