Euchner 075377E | SPIRALLEITUNG 23 ADRIG 3,5M : Spiral Cable
The SPIRALLEITUNG 23 ADRIG 3,5M Spiral Cable is designed for flexible connections, ensuring reliable electrical performance.
| Attribute | Value |
|---|---|
| Connection Type: | flying lead |
| Item designation: | SPIRALLEITUNG 12-ADRIG 5,4M |
| Gross weight: | 0,425kg |
| ECLASS: | 27-06-03-04 Appliance cord (data cable) |
| Dynamic bending radius: | 15 x cable diameter |
| Static bending radius: | 10 x cable diameter |
| Cable ambient temperature (dynamic): | -10 … +70 °C |
| Cable ambient temperature (static): | -40 … +80 °C |
| Cable length: | 5.4 m(extended) |
| Cable shielding: | yes(Cu thread covering, optical coverage approx. 90%) |
| Specific Conductor Resistance: | max. 145 ?/km |
| Conductor Identification: | Color code according to DIN 47100 |
| Conductor Cross-section: | 0.14 mm² |
| Number of conductors: | 12 |
| Cable Type: | coiled |
| Cable diameter: | 6.0 mm -0,3 … +0,3 mm |
| Sheath Color: | black matte |
| Conductor End: | trimmed smooth |
