| Connection Cross Section: |
0.5 … 1.5 mm² |
| Rated insulation voltage Ui: |
250 V |
| Rated impulse voltage Uimp: |
2.5 kV |
| Short circuit protection according to IEC 60269-1: |
6A gG |
| thermal rated current Ith: |
10 A |
| Number of NO contacts: |
1 |
| Number of positively driven contacts: |
3 |
| Actuating force: |
175 N |
| Installation Orientation: |
any |
| Mechanical Life: |
0.1 x 10? |
| Switching principle: |
Slow-action switching contact |
| Degree of protection: |
IP67 |
| Ambient temperature: |
-30 … +80 °C |
| Item designation: |
RPS-M-2131SR175M |
| Gross weight: |
0,799kg |
| ECLASS: |
27-37-12-01 Emergency stop pull cord switch |
| Safety Class: |
I |
| Additional feature: |
Emergency stop function |
| Actuation frequency: |
max. 1200 1/h |
| Rope diameter: |
2 … 5 mm |
