| Approvals: |
TUV, cULus |
| Coding Level according to EN ISO 14119: |
Low |
| Technology: |
Coded Magnetic, Hall effect |
| Housing Material: |
Red, Polyester |
| Normally Closed Contacts: |
Up to 2 N/C Safety (When the Guard is Closed) |
| Normally Open Contacts: |
Up to 1 N/O Auxiliary (When the Guard is Closed) |
| Switching Distance: |
Sao 8mm / Sar 20mm |
| Response Time (OFF): |
60ms Maximum |
| Tolerance to Misalignment: |
5mm in any Direction from 5mm Setting Gap |
| Indication: |
Green LED when Guard is Closed |
| Connectivity: |
2m, 5m, 10m, M12 QC |
| Length: |
60mm |
| IP Rating: |
IP67 |
| Ambient Temperature: |
-25 … +80 °C |
| Storage Temperature: |
-25 … +80 °C |
| Power Consumption: |
25mA Max. |
| Maximum Switched Current (Outputs): |
200mA (Minimum Internal Resistance 8.5ohms) |
| Switching Frequency: |
1.0 Hz Maximum |
| Approach Speed: |
200mm/m. to 1000mm/s. |
| Cable: |
PVC 6mm O.D. Conductors 0.25 sq.mm |
| ISO 13849-1: |
Up to PLe Category 4 (if both channels are used with a PLe control device) |
| Pfhd: |
2.6 x 10-10 (1/h) |
| Proof Test Interval (life): |
20 years |
| Mttfd: |
866 years |
| UL Info: |
Type 1 Enclosures. Maximum temperature 50ºC plastic versions, 70ºC S/Steel versions. Maximum output 24V.dc 100mA. Powered by Class 2 or equivalent. |
| Diameter: |
M30 x 1.5 |
