| Coding Level according to EN ISO 14119: |
Low |
| Technology: |
Magnetic |
| Housing Material: |
316 Grade Stainless Steel |
| Normally Closed Contacts: |
Up to 2 N/C Safety (When the Guard is Closed) |
| Normally Open Contacts: |
Up to 1 N/O Auxiliary (When the Guard is Closed) |
| Tolerance to Misalignment: |
5mm in any direction from 5mm setting gap |
| Connectivity: |
2m, 5m, 10m, M12 QC |
| Length: |
41mm |
| Width: |
26mm |
| Height: |
13mm |
| IP Rating: |
IP67, IP69K |
| Ambient Temperature: |
-25 … +105 °C |
| Storage Temperature: |
-25 … +105 °C |
| Switching Frequency: |
1.0Hz max. |
| Approach Speed: |
200mm/m. to 1000mm/s |
| Cable: |
PVC 6.0mm OD Conductors 0.25 sq.mm |
| ISO 13849-1: |
Up to PLe Category 4 (if both channels are used with a PLe control device) |
| UL Info: |
Suitable for Direct Contact Zones in accordance with EHEDG guidelines. Through hole fixing that enables front mounting by hexagon head bolts to give no food trap areas. |
| Certificates: |
TUV, cULus |
| Contact Release Time: |
<2ms |
| Switching Current, Minimum: |
10V. Dc 1mA |
| Switching Voltage, Maximum (2NC): |
240V.ac / 24V.dc 1.0A. max. Fuse externally 0.8(F) |
| Auxiliary Circuits (NO): |
24V.ac/dc 0.2A. max. |
| B10d: |
3,300,000 cycles at 100mA load |
| Usage: |
8 cycles/hour 24 hours/365 days per year MTTFd is 470 years |
