Name: Idem 200019: KP-Ex 2NC 3M 4 core
Brand: Venus Automation
SKU: 200019
Availability: InStock
Rating: 5 (1 reviews)

Idem 200019: KP-Ex 2NC 3M 4 core | Tongue Interlock Switches

“Robust safety switch, designed for explosion-prone environments, ensuring secure interlock.”

Specifications Compliance & Variations

Attribute	Value
Approvals:	IECEx, cULus on LS-Ex Internal Contact Block
Technology:	Tongue Interlock (Non Locking)
Housing Material:	Red, Polyester
UL Info:	Comes with 3m of pre-wired cable (longer available on request). Actuator sold separately. ATEX Zones 1,21,2,22 II 2G Ex mb IIC T6 Gb II 2D Ex mb IIIC T80C Db
Actuator Entry Minimum Radius:	175mm Standard 100mm Flexible
Enclosure Protection:	IP67
Operating Temperature:	-25 … +60 °C
Switching frequency (LS-Ex):	1.0 Hz maximum
Mechanical Life Expectancy (ls-ex):	1,000,000 switches
Electrical Life Expectancy (ls-ex):	Tested to 1,000,000 cycles at 24V. 0.2A
Head Material:	Polyester or Stainless Steel
Maximum Approach/Withdrawal Speed:	600mm/s

Product Number	Variant Description
200019F-SS	KP-Ex 2NC 3M 4 core SS head flat actuator
200019A-10M	KP-Ex 2NC 10M 4 core std actuator
200019A	KP-Ex 2NC 3M 4 core std actuator
200026-SS	KP-Ex 2NC 2NO 3M 4 core SS head
200026PF-SS	KP-Ex 2NC 2NO 3M 4 core SS head PF actuator
200026PF	KP-Ex 2NC 2NO 3M 4 core PF Actuator
200026HF-SS	KP-Ex 2NC 2NO 3M 4 core SS head HF actuator
200026HFH-SS	KP-Ex 2NC 2NO 3M 4 core SS head HFH Actuator
200026HFH	KP-Ex 2NC 2NO 3M 4 core HFH SS Actuator
200026HF	KP-Ex 2NC 2NO 3M 4 core HF Actuator
200026F-SS	KP-Ex 2NC 2NO 3M 4 core SS head flat actuator
200026F	KP-Ex 2NC 2NO 3M 4 core flat actuator
200026A-SS	KP-Ex 2NC 2NO 3M 4 core SS head std actuator
200026HFH-10M	KP-Ex 2NC 2NO 10M
200026-10M	KP-Ex 2NC 2NO 10M
200026	KP-Ex 2NC 2NO 3M
200019-SS	KP-Ex 2NC 3M 4 core SS head
200019PF-SS	KP-Ex 2NC 3M 4 core SS head PF actuator
200019PF	KP-Ex 2NC 3M 4 core PF Actuator
200019HF-SS	KP-Ex 2NC 3M 4 core SS head HF actuator
200019HFH-SS	KP-Ex 2NC 3M 4 core SS Head HFH SS Actuator
200019HFH	KP-Ex 2NC 3M 4 core HFH SS Actuator
200019HF	KP-Ex 2NC 3M 4 core HF Actuator
200019F	KP-Ex 2NC 3M 4 core flat actuator
200019A-SS	KP-Ex 2NC 3M 4 core SS head std actuator
200026-A	KP-Ex 2NC 2NO 3M 4 core std actuator
