“Mitsubishi R60DAI8 – 8 Channel Current Output, 0-32000 0-20mA DC | 80 ?s/CH”
$2,154.00
8 channels for current outputs; 0…32000, 0…20 mA DC; 80 ?s/CH
| Series: | MELSEC IQ-R SERIES |
| Type: | CHANNEL ISOLATED ANALOG OUTPUT |
| Current Type: | DC |
| Integrated Analogue Outputs: | 8 |
| Depth (mm): | 110 |
| Weight (kg): | 0,21 |
| Width (mm): | 27,8 |
| Height (mm): | 98 (106) |
| CE: | COMPLIANT |
| EAC: | NON-COMPLIANT |
| Ul/cul: | COMPLIANT |
| UKCA: | COMPLIANT |
| Aluminum (g): | 0 |
| Others (g): | 0 |
| Styrofoam (g): | 0 |
| Cardboard (g): | 45 |
| Steel (g): | 0 |
| Glass (g): | 0 |
| Other plastic (g): | 3 |
| Wood (g): | 0 |
| Other paper (g): | 25 |
| REACH Limit Exceeded: | YES |
| RoHS Compliance: | COMPLIANT |
| Dangerous Goods Class: | NO |
| WEEE: | B2B |
| Dangerous Goods Identifier: | NO |
| REACH Substance CAS Number: | 119313-12-1, 80-05-7, 80-43-3, 71868-10-5 |
| Shipping Approvals: | ABS,BV,DNV GL,LR,NK,RINA |
| Int. Current Consumption (A): | 0,18 |
| Occupied I/O Points On PLC: | 16 |
| Wiring: | SCREW |
| Power Supply (V): | 24 |
| Output Voltage Range (V): | -12-12; -10-10; 0-5; 1-5 |
| Output Current Range (mA): | 0-20; 4-20 |
